Plantar Fasciitis vs. Heel Spur: What's the Difference?
Share
If you've had an X-ray for heel pain, you may have heard one of two things: "you have plantar fasciitis" or "you have a heel spur." Sometimes the same person hears both. The confusion around these two conditions is remarkably common — and the conflation matters, because they have different causes, different implications, and different treatment approaches.
What Is Plantar Fasciitis?
Plantar fasciitis is inflammation and degeneration of the plantar fascia — the thick band of connective tissue that connects your heel bone (calcaneus) to the base of your toes. It supports the arch of the foot and acts as a shock absorber during walking and running.
When the fascia is repeatedly overstressed — through flat arches, tight calves, inadequate footwear, or sudden increases in activity — it develops micro-tears at or near the heel attachment point. The resulting inflammation and degeneration is what we call plantar fasciitis.
The condition is clinical. It's diagnosed based on symptoms: sharp heel pain with first steps, tenderness at the medial heel, pain that eases with activity then returns. Imaging is not required for diagnosis.
What Is a Heel Spur?
A heel spur (calcaneal spur) is a calcium deposit — a bony outgrowth — on the heel bone. It typically forms over time as a response to the repeated stress and tension on the heel. The body, attempting to reinforce an area under chronic stress, lays down extra bone material.
Heel spurs are visible on X-ray, which is the only way to confirm they're present. They can point forward (inferior heel spur, at the plantar fascia attachment) or backward (posterior heel spur, at the Achilles tendon insertion).
An inferior heel spur — the most common type associated with heel pain — forms directly at the site where the plantar fascia attaches to the calcaneus.
The Relationship Between the Two
Here's the key fact that most people get wrong: a heel spur is not the cause of plantar fasciitis pain.
The two conditions frequently coexist. Studies show that around 50% of people with chronic plantar fasciitis also have a heel spur visible on X-ray. This has historically led to the assumption that the spur is causing the pain.
But research doesn't support that. Here's the evidence:
- Up to 15–20% of people with heel spurs have no pain at all
- Removal of heel spurs does not reliably relieve plantar fasciitis pain
- People with and without heel spurs have similar outcomes with plantar fasciitis treatment
- The pain in plantar fasciitis originates in the fascia tissue, not the bone
The heel spur is better understood as a consequence of the same chronic tension that causes plantar fasciitis — a bony adaptation to repetitive stress — rather than the cause of the pain itself. The treatment target is the fascia, not the spur.
Why the Distinction Matters
Treatment Is the Same
Whether you have plantar fasciitis alone or plantar fasciitis with a heel spur, the treatment is essentially identical: stretching, appropriate footwear, custom orthotics, and load management. Treating the spur directly is rarely indicated.
Surgery Implications
Historically, plantar fascia release surgery sometimes included removal of the heel spur. Current evidence suggests the spur removal doesn't add benefit — outcomes are similar with or without it. Most surgeons today focus on the fascia release rather than spur removal.
If a surgeon is recommending heel spur removal as the primary target of surgery, it's worth a second opinion.
Don't Let the X-Ray Redirect Your Treatment
Some patients who receive an X-ray showing a heel spur become focused on "fixing the spur" — which often leads to ineffective or unnecessary treatments. The spur is not the problem. The inflamed, overloaded fascia is the problem.
How to Tell Which You Have
Practically speaking, you may have both — and from a treatment standpoint, it doesn't change much. But here's how they differ diagnostically:
| Plantar Fasciitis | Heel Spur | |
|---|---|---|
| How it's diagnosed | Clinical (symptoms, physical exam) | X-ray only |
| Visible on imaging | Not on X-ray; may show on MRI/ultrasound | Yes — on X-ray |
| Causes pain | Yes, the primary source of heel pain | Usually no |
| Requires treatment itself | Yes | Rarely |
| Responds to stretching/orthotics | Yes | N/A (not a tissue condition) |
Other Conditions That Can Mimic Plantar Fasciitis
It's worth knowing that not all heel pain is plantar fasciitis or heel spur-related:
Baxter's nerve entrapment: Compression of the first branch of the lateral plantar nerve. Causes heel pain that closely mimics plantar fasciitis but doesn't respond to the same treatment. Distinguished by nerve-specific testing.
Fat pad atrophy: The fat pad under the heel thins with age, reducing natural cushioning. Pain is more diffuse and present throughout the day rather than concentrated at first steps. More common in older patients.
Achilles tendinopathy: Pain at the back of the heel (where the Achilles tendon attaches), not the bottom. Occasionally confused with posterior heel spur.
Calcaneal stress fracture: More common in high-mileage runners. Pain throughout the heel, often with point tenderness at the sides of the calcaneus. Requires rest, not orthotics.
Tarsal tunnel syndrome: Compression of the tibial nerve as it passes through the tarsal tunnel on the inside of the ankle. Often presents with burning or tingling in addition to heel pain.
If treatment for plantar fasciitis isn't working after 8–12 weeks, one of these alternative diagnoses should be considered.
Frequently Asked Questions
I have a heel spur. Do I need surgery?
Almost certainly not. Heel spurs in the absence of severe, treatment-resistant pain rarely require surgery. The vast majority of people with heel spurs never need any intervention for the spur itself.
My doctor said my pain is from the heel spur. Is that wrong?
The spur may be in the same location as your pain and visible on X-ray — but that doesn't mean it's the cause. Current evidence strongly supports treating the plantar fascia (the soft tissue) rather than the spur (the bone) as the primary target. Conservative care (orthotics, stretching, footwear) addresses the root cause.
Will the heel spur go away with treatment?
No. Once formed, heel spurs are permanent bony structures. They don't reabsorb. But because they're typically not causing the pain, their persistence isn't clinically relevant for most patients.
Can plantar fasciitis cause a heel spur?
Yes — in the sense that the same repetitive stress that causes plantar fasciitis also creates the traction forces that stimulate bone spur formation. The two conditions develop from the same underlying mechanical problem.
Both conditions involve the heel and often coexist, but the meaningful treatment target is almost always the plantar fascia — not the spur. If you've been told you have a heel spur and haven't found relief, the approach should focus on the soft tissue mechanics driving your pain.
